How I passed Istio Certified Associate, ICA

| Tags: Istio , Service Mesh , Kubernetes | 4 min read
ICA attained

The Istio Certified Associate, ICA is a challenging and practical hands on exam. To help learn a capability I like the idea of an exam based goal, it’s achievable and ensures I attain a strong understanding of the system.

Building a question and problem solving routine

I used the following workflow, to methodically tackle each question. I found the routine helpful as it developed muscle memory and was one less thing to have to remember.

  • At the start of each question there is a hyperlink to the relevant Istio documentation, I strongly advise using this.
  • I had a single terminal window open, and at the start of each question, used the provided ssh <server> to login to the server.
  • If the question required investigation, I would gather information and use this to inform the answer.
  • Using the provided VS Chromium, I created a new tab for each question. I copied the relevant manifests from the documentation, modified to solve the question. Once happy I copied the manifests to the clipboard.
  • In the Terminal, I used vim to create a yaml file, and pasted the saved manifest (Ctrl, Shift, V) and saved (Shift zz).
  • Some questions required editing a resource, in this case I still used the VS Chromium editor for the manifest snippet and pasted into the resource and saved.
  • On the command line I executed either istioctl and/or kubectl, to apply the changes. Any errors I fixed in VS Chromium and repeated above steps.
  • If the question provides a curl or cli command to validate, do execute it, if it fails validation, I gave myself a minute to investigate but if I couldn’t resolve I’d flag the question and move on to the next one.
  • Ensure I exit the terminal session and move onto the next question.

Breaking down the Domains & Competencies

Installation, Upgrades, and Configuration – 20%

Installing Istio with istioctl or Helm

  • Be very familiar with istioctl install/analyze options.

Installing Istio in Sidecar or Ambient Mode

  • Ensure you you understand enabling/disabling the sidecar on pods and namespaces.

Customizing your Istio Installation

  • Ensure you understand the IstioOperator and customizing the components.

Upgrading Istio (Canary, In-Place)

  • Practice Istio canary and in-place upgrades, I used my Mac to practice the upgrades using Istio on Kind.

Traffic Management – 35%

Configuring Ingress and Egress Traffic

Configuring Routing within a Service Mesh

Defining Traffic Policies with Destination Rules

Configuring Traffic Shifting

Connecting In-Mesh Workloads to External Workloads and Services

Using Resilience Features (circuit breaking, failover, outlier detection, timeouts, retries)

Using Fault Injection

  • This section is all about being familiar with the Istio resources. I practiced this over and over using, this slightly outdated but still brilliant Killercoda Istio practice. Again I built up a strong familiarity, on these areas, and could lean into the presented problems.

Securing Workloads – 25%

Configuring Authorization Configuring Authentication (mTLS, JWT) Securing Edge Traffic with TLS

  • Again this section is all about being familiar with the Istio resources. As mentioned I used the killercoda practice exams and the Istio help pages to solve the problems.

Troubleshooting – 20%

Troubleshooting Configuration Troubleshooting the Mesh Control Plane Troubleshooting the Mesh Data Plane

  • I found this to be the toughest area. Under exam and time pressure, you need to have a method to help diagnose the issue(s). The advice I suggest is to become familiar with the Istio scenarios described in the troubleshooting documentation. Use istioctl analyze, kubectl logs, kubectl get po/deploy POD --o yaml and kubectl rollout restart to diagnose and solve. Easy to say, but stay focused, don’t panic, timebox effort and move on.

Summary

There were 16 questions, in the exam I took, I’d completed the first pass in about 90 minutes. This left 30 minutes to review flagged questions and figure out the incomplete troubleshooting questions. I actually spent the majority of this time on troubleshooting. This was a tougher exam that the associate label suggests. But it’s worth it if your organization is currently using or planning to use Istio. Finally I attained the credly cert.
